It is a highly prefabricated curtain wall system. The curtain wall unit modules are assembled, sealed, and preliminarily debugged in the factory, and then transported to the construction site for hoisting and splicing.
Border Color
Features
| Main Thickness | 4.0mm/3.0mm |
| Mullion Specification | 110mm x 182mm |
| Transom Specification | 110mm x 162/182mm |
| Glazing Rebate | 43mm |
| Exterior Cover Cap Specification | 110mm x 54mm |
| Materials Data | 10kg/m²～18kg/m² |
| MOQ | 250~500kgs/section |
| Delivery Time | 10~20days |
| Alloy | 6063-T5/T6 |
| Surface Treatment | Anodized and electrophoresis, powder coated, fluorocarbon |
| Remarks | We support a variety of customization requirements, including but not limited to length, width, thickness, etc. |
This unitized curtain wall uses high-strength aluminium profiles as the main frame material, combined with double-layer hollow glass, insulation strips and other configurations, so that the curtain wall system has excellent sealing and energy saving, and is an ideal choice for the facade system of modern high-rise buildings.
The aluminium profiles we use are all high-strength 6063-T5/T6 standards, with excellent corrosion resistance, lightness, and processability. At the same time, the profile surface can be anodized, electrophoresed, powder-coated, or wood grain transfer processed according to customer needs. It has a variety of appearances, strong weather resistance, and is suitable for various climate conditions.
High-strength narrow-frame windows maximize sunlight, offer versatile openings with screens, and enhance aesthetics with sleek, flush exteriors.
Exposed Frame Glass Curtain Wall 160
The aluminium curtain wall offers excellent weather resistance, thermal insulation, structural reliability, and long-term durability.
Hidden Frame Glass Curtain Wall JTLD160
Adopting a hidden frame design, the curtain wall features a clean and modern appearance, resulting in a more transparent and streamlined visual effect.
Insulated Glass Curtain Wall GMQ120
The curtain wall system is a high-performance facade solution designed with premium-grade aluminium profiles and double-glazed insulated glass.
Semi-Hidden Frame Curtain Wall SMG
A semi-hidden vertical or horizontal frame design is used to create a smooth and continuous glass curtain wall, while high-quality aluminium profiles provide stable support.
