The benefits of using aluminum photovoltaic brackets

June 27, 2026
4

Using aluminium photovoltaic supports can be regarded as choosing a “light, sturdy and extremely durable”framework for your power station.

Its advantages are particularly prominent, especially in terms of the relief of roof load, the ease of later maintenance, and the long-term economic benefits. It can be said that in the current photovoltaic market, aluminium supports are the mainstream choice that integrates performance, economy and environmental friendliness.

Overview of Core Advantages

Advantage Category	Specific Benefits	Significance
Lightweight & High Strength for Safer Roofs	Weigh only around 60% of steel mounts, achieving a 40% weight reduction.	Eliminates load-bearing concerns for old factories and light steel roofs; installation is feasible without structural reinforcement.
Corrosion Resistant & Maintenance-Free with Extra-Long Service Life	A natural oxide film forms on the surface to resist salt spray corrosion. With anodizing treatment, the service life exceeds 30 years.	The top choice for coastal areas, industrial zones and other high-humidity, highly corrosive environments; no repainting required throughout its lifespan.
Stable Structure Resisting Extreme Weather	Special aluminum alloys such as 6005 and 6061 feature high mechanical strength, capable of withstanding 60m/s strong winds (approx. Category 17 typhoon) and 2.5-meter snow load.	Guarantees structural stability and safety of power stations during their 25-year service life in typhoon and heavy snow regions.
Easy Installation Saving Time & Labor Costs	Highly pre-assembled, weld-free and connected via modular fittings to drastically boost installation efficiency.	Greatly shortens construction periods and cuts labor expenses, ideal for projects with tight schedules.
Superior Heat Dissipation to Boost Power Generation	Aluminum boasts excellent thermal conductivity, lowering the operating temperature of PV modules.	Effectively mitigates power output loss caused by overheating under high-temperature conditions.
Eco-Friendly with High Residual Value	100% recyclable material; energy consumption for remelting recycled aluminum is merely 5% of that for virgin aluminum production.	Mounts retain high residual value after project decommissioning, aligning with the full-life-cycle philosophy of green energy.

Selection Guidance for Different Application Scenarios

Rooftop projects (especially commercial & industrial color steel tile roofs): Aluminum mounts serve as the optimal solution to insufficient roof load capacity. Their light weight, paired with optional non-penetrating clamp systems, prevents damage to the original waterproof layer and eliminates hidden risks of water leakage and subsequent maintenance costs.

Ground-mounted PV power stations: Aluminum mounts deliver outstanding performance thanks to exceptional weather resistance (against sandstorms and salt spray) and flexible adjustable installation angles. From a full life-cycle perspective, their lower Total Cost of Ownership (TCO) and high recycling residual value often make them more cost-effective than steel alternatives.

Special climate zones (coastal, high-humidity and industrial areas): For these highly corrosive environments, aluminum mounts are virtually the unrivaled choice by virtue of inherent anti-corrosion properties, securing stable operation of power stations for 25 years.

In summary, choosing aluminum photovoltaic mounting structures means making a one-time reasonable investment in exchange for higher power generation revenue, lower maintenance costs and greater peace of mind throughout the entire service life of your PV station.
